Circuit Board XYZ Probe Positioner Set

https://www.optotherm.com/web/image/product.template/1165/image_1920?unique=b78690b

-Description-
Make probe connections to pads, vias, and components on PCBs and PCBAs. The two XYZ probe positioners mount to a metric mounting table, reach up to 300mm away from their base, and are fully adjustable to all angles. Recommended for probing circuit boards up to 18x24 inches (~508x610mm).

-Included Components-
(x2) XYZ probe positioners, assorted needle probes, and mounting hardware

-Features-
Up to 300mm reach, course and fine adjustments, fully adjustable to all angles

-More Information-
https://www.optotherm.com/shop/1165


Internal Reference: PN0295

Explore this product

OverviewApplicationsSpecifications

Overview

Allows the probing camera to be manually positioned in any orientation when probing both circuit boards and semiconductor devices. The arm is very rigid with minimal sag and is comprised of aluminum joints with PTFE bearings, rubber-coated steel knobs, and steel threaded posts.  Needle bearings provide smooth adjustment of joint friction.  A ball swivel clamp with thumb screw enables a wide range of camera viewing angles.  The arm mounts on a rigid stainless steel 40 mm post and provides 500 mm reach and weighs 1.6 Kg.

Applications

  • Circuit board probing
  • Semiconductor device probing

Specifications

Manual XYZ Arm Specs

Reach radius300mm
Weight1.6 kg

Video Cameras - Common

Probing Camera Macro Zoom Lens- Common
