16A Equipment Rack Power Distribution Unit
PN0399 has a total of 14 outlets (12 C13 and 2 C19) and a 16A circuit breaker.
Applications
Overview
Included Components
Required Products
Related Products
Manufacturer Information
Specifications
| 14 total outlets |
4 C13 in front, 8 C13 and 2 C19 in rear |
| Input Connection |
C20 input with 3.05 m (10-ft) cord and 5 plug adapters ( C14, NEMA L6-20P, NEMA L5-20P, NEMA 5-20P and NEMA 5-15P) |
| Mounting |
1U horizontal or 0U vertical mounting in EIA-standard 19 in. racks |
| Voltage - Input |
100 ~ 240V |
| Current - Max |
16A |
| Grounding |
Rear-panel grounding lug |
| Housing Material |
Steel |
| Unit Dimensions (hwd / cm) | 4.44 x 44.45 x 10.8 |
| Weight | 1.5 kg (3.2 lbs.) |
| Approval Agency |
CE, CSA, UL |
Setup
Figure 1:
Operation
Troubleshoot
Maintenance
